P1.538 Foldable Poster GOB LED Display for hotel airport exhibition Shop Advertising
Feature
HD Image Quality
Refresh rate up to 3840Hz;
Brightness at 800nits, 3 times brighter than LCD display;
160°view angle;
High color reproduction;
Compare with indoor LCD poster, with high brightness, super thin & low-power consumption,
LED Digital poster is also suitable for bright occasion.
Product specification
| Item | Technical parameter |
| Pixel Pitch | 1.538mm |
| Module Resolution | 208*104 dots |
| Module Size | 320*160mm |
| Pixel configuration | 1R1G1B |
| Module Chip | Kinglight/Nationstar |
| Driving Method | 1/52Scan |
| Physical Density | 422,500 dots/m2 |
| LED Encapsulation | SMD1212 |
| Module Port | BUH75 |
| Module Consumption | ≤16W |
| Brightness | 800 cd/m2 |
| Cabinet Dimension | 640*1920mm |
| Cabinet External Dimensions | 700*1980*100mm |
| Cabinet Resolution | 416*1248 dots |
| Quantities of module | 2*12 |
| Cabinet Flatness | Tolerance of inter pixel ≤0.3mm |
| Cabinet Material | Aluminume,Iron |
| Cabinet Weight | 42KG |
| Option Distance | 2--80M |
| Viewing Angle | Horizontal 140° Vertical 120° |
| Max. Power consumption | 675W/sqm |
| Driving Device | FM6363 |
| Frame Frequency | 60Hz |
| Screen Flatness | Tolerance of cabinets ≤0.6mm |
| Refresh Frequency | 3840Hz |
| Control Mode | Wifi asynchronization |
| Working Environment | Temperature -10℃~60℃ Humidity 10%~70% |
| Display Working Voltage | AC100-240V , 50Hz/60Hz |
| Colour temperature | 8500K-11500K |
| Communication distance | Network cable: 100m, Multi-model: 500m, Single-model fiber: 20km |
| Gray scale | ≥16.7M |
| MTBF | >10,000 hours |
| Support video source | HDMI, CVBS, SDI , DVI etc |
Control Methods
Synchronized / asynchronous system
Plug and play, Cross-platform operation
Real time play by connecting to network;
The screen can be controlled with fixed or portable Windows,
IOS & Android devices.
The content can be refreshed and stored in built-in media player
through WIFI or USB to achieve asynchronous play.
Multi-installation Method
Multi-installation Method Suitable for lifting, wall-mounted, floor-standing and creative installation like inclined strut installation
Our serrvices
1. Service before sales
On-site inspect
Professional design
Solution confirmation
Training before operation
Software use
Safe operation
Equipments maintenance
Installation debugging
Installation guidance
On-site debugging
Delivery Confirmation
2. After sale service
Quick response
Prompt question resolving
Service tracing
3. Service concept:
Timeliness, considerateness, integrity, satisfaction service.
We are always insisting on our service concept, and proud of the trust and reputation from our clients.
4. Service Mission
Answer any question; Deal with all the complaint; Prompt customer service
We had developed our service organization by responding to and meeting the diverse and demanding needs of customers by service mission. We had become a cost-effective, highly skilled service organization.
5. Service Goal:
What you have thought about is what we need to do well; We must and will do our best to fulfill our promise. We always bear this service goal in mind. We can't boast the best, yet we will do our best to free customers from worries. When you get problems, we had already put forward solutions before you.
